ISO630 Q195 Unequal Angle Bar 100x63x10 Hot Rolled Carbon Sheet Metal Beam

1 ton
MOQ
Negotiation
Price
ISO630 Q195 Unequal Angle Bar 100x63x10 Hot Rolled Carbon Sheet Metal Beam
Features Gallery Product Description Request A Quote
Features
Specifications
Name: Q195 Carbon Steel Unequal Angle Bar
Thickness: 10mm
Size: 100 * 63
Application: Construction
Grade: Q195
Color: Black
Technique: Hot-rolled
Type: Unequal Angle Bar
Certificate: ISO 9001
Standard: ASTM
Highlight:

Q195 Carbon unequal angle bar

,

ISO630 unequal angle bar

,

63x10 carbon sheet metal beam

Basic Infomation
Place of Origin: China
Brand Name: XUDA
Payment & Shipping Terms
Packaging Details: Standard seaworthy packing
Delivery Time: 3-5 work days
Payment Terms: L/C, T/T
Supply Ability: 1000 ton per month
Product Description

Product Description

Q195 Carbon Steel Unequal Angle Bar 100 *63 * 10mm Size Construction Use Hot-Rolled





ANGLE STEEL
Angle steel can be composed of different stress components according to the different needs of the structure, and can also be used as the connection between components.

It is widely used in various building structures and engineering structures, such as
beams,Bridges, transmission towers and warehouse shelves.



  • Introduction of Carbon Steel Angle bars



EQUAL ANGLE (A*T)
Size(mm)
Theoratical Weight
(kg/m)
Size(mm)
Theoratical Weight
(kg/m)
Size(mm)
Theoratical Weight
(kg/m)
25*3
1. 134
75*7
7.976
110*14
22.809
25*4
1. 459
75*8
9.03
125*8
15.504
30*3
1. 373
75*10
11. 089
125*10
19. 133
30*4
1. 786
80*6
7.376
125*12
22.696
40*3
1. 852
80*7
8.525
125*14
26. 193
40*4
2.422
80*8
9.658
140*10
21. 488
40*5
2.976
80*10
11. 874
140*12
25.522
50*4
3.059
90*6
8.35
140*14
29.49
50*5
3.77
90*7
9.658
140*16
35.393
50*6
4.465
90*8
10.946
160*10
24.729
60*5
4.52
90*10
13.476
160*12
29.391
60*6
5.42
90*12
15.94
160*14
33.987
63*5
4.822
100*6
9.366
160*16
38.518
63*6
5.721
100*7
10.83
180*12
33. 159
63*8
7.496
100*8
12.276
180*14
38.518
63*10
9. 151
100*10
15. 12
180*16
43.542
70*5
5.397
100*12
20.611
180*18
48.634
70*6
6.406
100*16
23.257
200*14
42.894
70*7
7.398
110*7
11. 928
200*16
48.68
70*8
8.373
110*8
13.532
200*18
54.401
75*5
5.818
110*10
16.69
200*20
60.056
75*6
6.905
110*12
19.782




  • Carbon Steel Angle bar Properties and Showcase



Product
angle bar beam steel angle bar
Size
20#~250#
Thickness
3mm~35mm
Length
6M/9M/10M/12M, OR Cut as your demands
Technique
Cold Drawn/ Cold Pilfered/ Cold Rolled/ Hot Rolled/ Forged
Other processing service
Hot dip Galvanized, Pre-galvanized, Color Painting, Coated, Cutting, Bending,
Punching as long as you can tell us your requirement.
Offer Standards
ASTMA53/ASTM A573/ASTM A 283/ASTM A36
BS1387-1985/BS EN10025/BS970
GB/T3091-2001, GB/T13793-92, ISO630/E235B/
JIS G3101/JIS G3136/JIS G3106
DIN17100/DIN 1.0038/DIN1025-5
Materials
A36
Q235/Q235B/Q345/Q345B/
S235JR/S235/S355JR/S355/ST37-2/ST52-3/
SS400/SM400A/SM400B/SS490/SM490/SS540
stainless: 200/300/400 series
MTC Report or any other requested test can be offered together with shipping document
PAYMENT TERMS :
1.100% irrevocable L/C at sight.
2.30% T/T prepaid and the balance against the copy of B/L.
3.30% T/T prepaid and the balance against L/C
Brand
Jinxi steel ,Ma Steel,Laiwu steel,Rizhao steel,Tang Steel
Certificate
ISO, SGS, CE, CQC and third part inspection.



ISO630 Q195 Unequal Angle Bar 100x63x10 Hot Rolled Carbon Sheet Metal Beam 0



  • Factory Introduction




ISO630 Q195 Unequal Angle Bar 100x63x10 Hot Rolled Carbon Sheet Metal Beam 1



    Jiangsu Xuda Steel company has deeply engaged in Chinese domestic market for over 10 years. We established perfect reputation and deep co-operations with large number of reliable patners. Our high-tech factory and well-trained workers are able to manufature best quality and highly customized metal products. The professional sales team guarantes the prefect trading experience with Xuda.

    The goal of Xuda is doing our best to offer our clients best service and product quality with lowest price. We are looking forward to deal business with you!



  • Certificates

ISO630 Q195 Unequal Angle Bar 100x63x10 Hot Rolled Carbon Sheet Metal Beam 2



  • FAQ



1. What is your payment terms?

Xuda Steel prefers 30%TT before inspection and the rest 70% against BL. However, our price term is negotiable. Multiple payment terms are available from us.



2. Which payment method can I choose?

Xuda Steel accepts all types of secured payment methods. Bank transaction, Alibaba Trading Assurance, Paypal and etc are all available from us. Please feel free to contact us about your preferred payment method.



3. Is sample providing service available?

Xuda Steel provides free samples to our clients. We usually also cover the sample shipping cost. Please feel free to order a sample from us.



4. Is customization available?

Xuda Steel’s expert equipment and highly-trained workers are capable of manufacturing highly customized products. Please fel free to discuss with us about your customized requirements, we can surely meet your needs.



5. What products and materials do you supply?

Xuda Steel mainly supplies all catalogs and all grades of steel and stainless steel products. Coils, strips, sheet, pipes, bars, beams, flanges and other customized products. Tin coating, Ti coating, galvanization and other surface treatments are also available.

Other than steel products, Xuda Steel also has high production capacity and holds large ready stock of all kinds of copper and aluminum products. Please feel free to consult us about any related products above, we can surely meet your requirements.



6. Why should I choose you?

Jiangsu Xuda Steel Industry company has deeply engaged in metal material market for over 15 years. We established perfect reputation world-widely. Craftsmanship spirit is the fundamental of Xuda Steel since we are established. Xuda Steel keeps our products as highest quality and lowest price to maintain our self competitive. Proving our clients with best trading experience is the goal we always insist of.



7. How can I make sure you are a reliable supplier?

Xuda Steel is willing to provide our copies of company registration certificate, Alibaba registration and Chinese exporting registration for you to view. These certificates are under Chinese Trading Law effect. They can help you officially check our company s capability and status.

On the products' side, certificates as Mill Test Certificate(MTC), Third Party Material Quality Conformity Certificate and other required certificates are available before the order. Samples are also available from us for you to test in your own testing facility. Xuda Steel also supports third-party inspection before shipping. Xuda Steel also welcomes a company tour for you to check our factory status.
